Circular Screen

Circular Screen Equipment

Adhering too stringent quality control procedures we offer you state of the art circular screen equipment with robust design, reliability and tremendous performance. Our circular screen comes with a smooth screening surface with no sharp edges, burrs or acute angles. The filters are uniformly cut by specially designed computer-based technology, to avoid the uneven edges. As one of the leading manufacturers, exporters and wholesale suppliers of circular screen equipment, we strive to provide, customized circular screens with absolute zero wastage.

Circular Screen Product Specifications
STANDARD EXTRUDER SCREEN SPECIFICATION
MESH
WIRE DIA. MM
APERTURE SIZE MM
OPEN AREA
10 X 10
0.711
1.829 MM
51.8
14 X 14
0.457
1.357 MM
55.9
16 X 16
0.457
1.131 MM
50.7
20 X 20
0.559
0.711 MM
31.4
20 X 20
0.457
0.813 MM
41.0
24 X 24
0.376
0.682 MM
41.4
30 X 30
0.376
0.531 MM
34.2
30 X 30
0.310
0.536 MM
40.0
40 X 40
0.274
0.361 MM
32.3
50 X 50
0.193
0.335 MM
43.6
60 X 60
0.193
0.230 MM
29.8
80 X 80
0.122
0.196 MM
37.9
100 X 100
0.102
0.152 MM
36.0
120 X 120
0.091
0.120 MM
31.8
150 X 150
0.071
0.088 MM
29.6
200 X 200
0.050
0.077 MM
36.76
250 X 250
0.040
0.062 MM
36.76
300 X 300
0.040
0.045 MM
27.83
325 X 325
0.035
0.043 MM
30.49
400 X 400
0.028
0.036 MM
31.25
500 X 500
0.025
0.026 MM
25.79
